Welcome to Porter Design, your trusted partner in architectural design across Southern Ontario. We are a certified, registered and insured BCIN (Building Code Identification Number) firm, offering innovative and functional architectural solutions that bring your vision to life.
At Porter Design, we specialize in a wide range of services, from residential and commercial projects to renovations and custom builds. With our expertise and in-depth knowledge of Ontario’s building regulations, we ensure each project is delivered to the highest standards of quality, safety, and compliance.
Our team is passionate about creating spaces that are both aesthetically pleasing and structurally sound. Whether you’re embarking on a new build or looking to refresh an existing space, we collaborate closely with clients to tailor designs that meet their unique needs.
Navigating the complexities of building permits can be overwhelming. At Porter Design, we simplify the process by managing your building permit applications from start to finish. Our team is well-versed in Ontario’s zoning laws and building codes, ensuring that your designs are fully compliant with all municipal requirements. We take care of the paperwork and coordination, so you can focus on your project.
In addition to our design services, we also offer comprehensive project management. From initial concept to final construction, we oversee every phase of the project, ensuring that it runs smoothly, on time, and within budget. Our goal is to make your experience stress-free, providing expert guidance and support at every step.
With Porter Design, expect professionalism, creativity, and a commitment to excellence. Let’s build your dream space together!
residential DESIGN SERVICES
Cover Page
The cover page includes a 3D render of proposed building, construction notes, window and door schedules and schedule of finishes.
Foundation or Basement Plan (1/4” = 1’ Scale)
The foundation plan layout shows the interior and exterior concrete walls and concrete footings. Including all required dimensions, notes, window and door locations for buck outs etc.
Detailed Floor Plans (1/4” = 1” Scale)
The first and or second floor plan (if required) provides the required dimensions, notes, windows, doors and floor finishes.
Framing Plans (1/4” to 1’ Scale)
The framing plan shows the floor, ceiling and roof plans if required, including member size and layout.
Cross Sections (1/4” to 1’ Scale)
A cross section is a vertical cut plane through the center of the building from the footings to the top roof line. This drawing includes the building details of the envelope, wall assemblies, and roof or truss assembly.
Exterior Elevations (1/4” to 1’ Scale)
The exterior elevations show architectural details, roof pitches, window and door styles, grade lines and exterior finishes. Drawing includes the front, rear, right and left exterior elevations.
Construction Details (1/4” to 1’ Scale)
Construction Details provide clarity to the construction of certain components of the design. Such as brickwork, steel beam connections, and beam supports etc.
All plans are designed to meet the Ontario Building Code. Plans are drawn in Imperial dimensions, contact your local municipality to inquire if Metric dimensions are required.
Please feel free to CONTACT US with any questions or inquiries regarding our building plans.
Permit applications
Permits, Variances, Clearances and Approvals
Depending on the complexity of your project
insured, QUALIFIED AND REGISTERED
BCIN = Building Code Identification Number.
House designers and design firms must have a BCIN to provide design service in Ontario. A completed "Schedule 1: Designer Information" form may be required with the submission of your "Application for a Permit to Construct or Demolish"
